Description
Specifications
• Four temperature options.
• Temperature selector on lower part.
• Angled siege.
• Compatible with DR circuit breakers (proctection against electric shocks).
• Silver electric contacts: increase lifetime of product.
• Lower installation pressure: beginning at 0.9 mwc.
• Two years warranty for plastic parts (check warranty ceritificate).
Colors
White
Technical Information
| Divina Ducha Alcance | |||||||
| Code | Power | Indicated circuit breaker | Indicated Heating element | ||||
| 127 V | 220 V | 127 V | 220 V | 127 V | 220 V | ||
| DDA55V1 | DDA55V2 | 5500 W | 50 A | 32 A | RED55V1 | RED55V2 | |
| – | DDA68V2 | 6800 W | – | 40 A | – | RED68V2 | |
| – | DDA75V2 | 7500 W | – | 40 A | – | RED75V2 | |
Regulation
Selo de Eficiência Energética
• Energy conservation program that authorizes use of information stamps to warn consumer of energy efficiency of electric equipment for instantaneous water heaters.
• . Authorization to use stamps is obtained through conformity of products according to regulation RESP/022 – AAQ, from INMETRO.
Quality Tests
• Current leakage test: to guarantee compatibility of electric shower with DR circuit breaker.
• Hydraulic test: to guarantee electric shower is working on low and high presure without water leakage.
• Performance and electric conformity test: to check if nominal power values and tension are according to specify.
